| IR Source |
High-efficiency LED array with current limited integral power circuit |
| Beam Patterns |
20° or 50° |
| Wavelength |
850 nm |
| Power consumption |
37 to 40 W (40 W max. power). Power consumption will vary over time due to the intelligent IR’s optical output control which compensates for LED degradation and ambient temperature fluctuations. |
| Model |
Horizontal Angle , AchievableDistance1 , Horizontal Field of View |
| LED-658-AM/SM |
20 , 54.3 m (178.1 ft) , 18.9 m (61.9 ft) |
| LED-658-AW/SW |
50 , 39.3 m (c ft) , 33.2 m (109.0 ft) |
| Dimensions (L x W x H) |
381 x 114 x 114 mm(11.01 x 4.5 x 4.5 in.) without sunhood or mounting cradle |
| Weight |
Stainless Steel: 12.7 kg (28 lb)Aluminum: 6.1 kg (13.5 lb) |
| Construction |
Electropolished 316L Stainless Steel or Anodized Aluminum |
| Bracket |
Pan(±36°)/Tilt(±45°),mounting cradle included |
| Cable Entry |
Four (4) 3/4-in. NPT entries |
| View Window |
9-mm thick borosilicate float glass |
| |
|
| Operating Temperature |
-50 °C to +60 °C (-58 °F to +140 °F) |
